iBrett – BSI Lighting

iBrett

iBrett is a range of urban lighting luminaires designed to provide excellent, environmentally friendly lighting without compromising on architectural appearance.

Elegant and comfortable solution for creating a warm ambiance.

PRODUCT
GALLERY
OPTICAL
TECHNICAL DATA
CODES
DOWNLOAD FILES

iBrett is an outdoor luminaire specially designed for urban areas and blends perfectly into the environment.

It is equipped with powerful LEDs that enables exceptionally uniform light distribution and provides perfectly homogeneous lighting without shadows.

The luminaire has very balanced and elegant proportions and is available in two different heights.

Architectural LED lighting luminaire range inspires architects, designers and system integrators with its exceptional quality, homogeneous illumination and remarkable creativity.

Designed to last in extremely harsh environments.

Distinctive and Effective

Clear and functional lines, high-performance optical modules, equipped with the latest technologies for intelligent lighting and energy efficiency, the iBrett urban post-top luminaire combines elegance and innovation with the highest quality of illumination without creating light pollution.

The luminaire with stylized appearance and with improvements in installation, maintenance and service life offers optimum light distributions that ensure effective values, visual comfort and light output for pedestrian areas and streets without light pollution. With the latest innovations, iBrett offers advanced lighting technology with refined aesthetics.

Modern Design and Easy to Install

The modernly designed luminaire, which is equipped with an integral power supply unit, is optionally available with DALI control or in the user-friendly On-Off version.

The product is supplied pre-wired, permitting simple, rapid and safe installation.‎

Individualize the System

We offer you extensive options for the individualization of the iBrett range.

To customize the system even more efficiently to your project requirements, more variants are available on request in addition to the standard configurations.

Architectural

Outdoor lighting performs a function that complements architecture. The extensive and modular range gives designers and architects the freedom to realize their designs and concepts.

Sustainable

BSI® Lighting Technologies follows smart, sustainable and ecologically responsible outdoor lighting principles using new technologies and best practices in product design and manufacturing.

Durable

Robust and reliable product with advanced components and materials, durable and able to withstand corrosion and mechanical impact.

GALLERY

OPTICAL

Rotational diffused beam

TECHNICAL DATA

Led Type

High efficiency LEDs, available in 2700K, 3000K, 4000K, 5000K, 6500K CCT tolerance within a 3-step MacAdams ellipse and LM80 compliant.

Colour Rendering Index

CRI ≥ 80 standard and CRI ≥ 90 on request.

Materials

Corrosion resistant double layer polyester powder coated paint finish die cast aluminium housing with stainless steel screws (A4 grade) and silicone gaskets. Power unit is built in. Available in anthracite gray as a standard finish or any desired RAL colour.

Optional Coating

Marine grade.

Diffuser

Shockproof PMMA UV Stabilised.

LED Life Time

L90 - B10 > 100,000h

Operating Temperature

-40°C / +55°C

Power Factor

>0.95

Conformity

Complies with European Standards EN 60598 and CE certified.
